NANOTECHCENTER

Description:

Barium titanate nanopowder produced by Ukrainian company NanoTechCenter processed in unique reactors by new improved technologies of reaction rate controlled synthesis under non-isothermal conditions, demonstrates properties competitive with respect to powders of global manufacturing industry leaders.

Barium Titanate Nanopowder (BaTiO3,Tetragonal) Certificate of Analysis-wt%

Na                 Ca         Fe           K             Mg         Sr
0.001          0.001    0.001      0.001     0.001     0.016
Ba/Ti                                       1.007

The powder is produced by environmentally-friendly technology from high quality unstable precursors and characterized by unprecedentedly small size (1530 nm), high surface area (2530 m² / g) and high chemical purity. Small size and high specific surface gives high reactivity of the powder, which can significantly reduce the sintering temperature, thereby reducing the grain size after sintering to obtain improved electrical characteristics of the final product.

Barium titanate nanopowder is an ideal for the preparation of ceramic suspensions subsequently using in advanced printing and casting technologies such as Ink Jet Printing, Screen Printing, Tape Casting, Spin Coating, etc. Ultra small size and structure of the powder particles allows them to pack in ultrathin ferroelectric layers (less than 1 micron) during casting or printing, resulting in miniaturization and improvement of electronics performance, where they are applied.

Purity: 99.9%
Average particle size (XRD): 15,6 nm
Average particle size (BET): 38 nm
Average particle size (TEM): 26 nm
Surface area: 25,6 m²/g (BET)
Average pore diameter 18,7 nm
Color: white
Morphology: near spherical
Crystallinity: Cubic (XRD)
True Density: 5,85 g/cm³
Bulk Density: 1,20 g/cm³
Tap Density: 1,65 g/cm³
Angle of natural slip: 40°
Spatula angle: 39°
Moisture (at 105°C, 2h): 0,43 wt%
Ignition Loss (at 1100°C, 1h): 1,5 wt%

Application:

Barium titanate are widely used in industry as piezoelectric, mainly in the form of ferroelectric and piezoelectric ceramics. Technical

Field of its application are:

• micro capacitors,
• dielectric amplifiers,
• memory cells,
• high-density optical data storage,
• nonlinear optics,
• optical data processing devices,
• dynamic holography devices,
• piezoelectric and pyroelectric transducers,
• thermistors,
• microphones,
• heaters,
• device of conversion and modulation of laser radiation.

Certificate-BaTiO3
